Wall Mounting Temperature and Humidity Transmitter/high Accuracy HVAC Transmitter (Temp. Range: 32 to 122°F & Humi.: 10 to 90% RH) for Hi Tech Workspaces, Beverage, Ducting Model: Rotronic HF120

The Rotronic HF120-WB1X1XX is a high-precision temperature and humidity transmitter with LCD display designed for industrial and commercial use. Offering excellent accuracy with a wide measurement range of -20 to 50°C / -4 to 122°F and 0 to 100% RH, it ensures reliable environmental monitoring. Its compact, IP65-rated housing makes it ideal for demanding environments. With versatile output options (4-20mA), it seamlessly integrates into existing systems. Featuring Rotronic’s renowned HygroClip sensor technology, it guarantees long-term stability and minimal drift. Perfect for applications in HVAC, BMS, data centers, cleanrooms, and more.

• Temperature Sensor: Measurement Range: -20 to 50°C / -4 to 122°F; Accuracy at 23°C ±5K; Response Time: 4 seconds.
• Humidity Sensor: Measurement Range: 0 to 100% RH; Accuracy: <±2 %RH; Long-Term Stability: 1.5 %RH per year; Response Time: 30 seconds (63% of rise from 35 to 80 %RH) without filter. Output: 4 to 20mA current or 0 to 10 VDC voltage.
• Transmitter Specifications: 2-wire type; Supply Voltage: 12 to 28 VAC / 15 to 40 VDC; Maximum Current Consumption: 40 mA (2-wire); Housing: ABS material, IP 65 rated for protection | Come with LCD Display
• Sensor Integration: Integrated within the device; Operating Range: -20 to 50°C / -4 to 122°F & 0 to 100% RH (non-condensing); CE/EMC Compliance: 2004/108/EC; Dimensions: 105mm x 32mm x 172mm.
• Supply Scope: 1 Unit of Temperature Humidity Transmitter, calibration certificate and Instruction Manual | Applications: HVAC Systems, Building Management Systems (BMS), Warehouses, Storage Areas, Clean Rooms, Museums, Art Galleries, Plastic Manufacturing, Data Centers.
